How to Combine Multiple Matplotlib Figures Into One Figure?

Published on
4 min read
How to Combine Multiple Matplotlib Figures Into One Figure? image

To combine multiple matplotlib figures into one figure, you can create subplots using the subplot() function. This function allows you to specify the layout of subplots within a single figure. You can specify the number of rows and columns of subplots, as well as the position of each subplot within the grid.

Once you have created your subplots, you can then use the plot() function to plot your data on each subplot. You can customize the appearance of each subplot using various plotting functions and options provided by matplotlib.

After plotting your data on each subplot, you can use the show() function to display the combined figure with all the subplots. This will allow you to visualize multiple figures together in a single plot, making it easier to compare and analyze your data.

How to save the combined figure as a single image file in matplotlib?

You can easily save a combined figure as a single image file in matplotlib by following these steps:

  1. After creating the combined figure using plt.subplots() or fig.add_subplot(), use the plt.savefig() function to save the figure as a single image file.
  2. Specify the file format you want to save the figure as by adding the file extension to the file name. Some common file formats for saving figures include PNG, JPEG, and PDF.
  3. Provide the file name and path as arguments to the plt.savefig() function to specify where you want to save the file. If you only provide the file name and not the path, the file will be saved in the current working directory.

Here's an example code snippet that demonstrates how to save a combined figure as a single image file:

import matplotlib.pyplot as plt

Create a combined figure with two subplots

fig, axs = plt.subplots(2)

Plot some data on the subplots

axs[0].plot([1, 2, 3], [4, 5, 6]) axs[1].plot([3, 2, 1], [6, 5, 4])

Save the combined figure as a PNG file named 'combined_figure.png'

plt.savefig('combined_figure.png')

plt.show()

After running this code, you will find a combined_figure.png file saved in the current working directory containing the two subplots as a single image.

What is the best way to organize multiple plots in one figure using matplotlib?

One of the best ways to organize multiple plots in one figure using Matplotlib is by using subplots. Subplots allow you to create multiple plots within a single figure and arrange them in a grid-like layout.

Here is an example of how you can use subplots to organize multiple plots in one figure:

import matplotlib.pyplot as plt

Create a figure and a set of subplots

fig, axs = plt.subplots(2, 2)

Plot on the first subplot

axs[0, 0].plot([1, 2, 3, 4], [1, 4, 9, 16]) axs[0, 0].set_title('Plot 1')

Plot on the second subplot

axs[0, 1].plot([1, 2, 3, 4], [1, 2, 3, 4]) axs[0, 1].set_title('Plot 2')

Plot on the third subplot

axs[1, 0].plot([1, 2, 3, 4], [4, 3, 2, 1]) axs[1, 0].set_title('Plot 3')

Plot on the fourth subplot

axs[1, 1].plot([1, 2, 3, 4], [1, 3, 5, 7]) axs[1, 1].set_title('Plot 4')

Adjust the layout

plt.tight_layout()

Show the plots

plt.show()

In this example, we create a 2x2 grid of subplots within a single figure using plt.subplots(2, 2). We then plot different datasets on each subplot and set titles for each subplot. Finally, we adjust the layout using plt.tight_layout() to ensure that the subplots are properly spaced out within the figure.

How to overlay multiple plots in the same subplot when combining figures in matplotlib?

To overlay multiple plots in the same subplot when combining figures in matplotlib, you can use the plt.plot() function multiple times within the same subplot. Here is an example code snippet to demonstrate how to overlay multiple plots in the same subplot:

import matplotlib.pyplot as plt

Create some sample data

x = [1, 2, 3, 4, 5] y1 = [10, 15, 13, 18, 20] y2 = [5, 8, 7, 10, 12]

Create a figure and subplot

fig, ax = plt.subplots()

Overlay the two plots in the same subplot

ax.plot(x, y1, label='Plot 1', color='blue') ax.plot(x, y2, label='Plot 2', color='red')

Add labels, title and legend

ax.set_xlabel('x-axis') ax.set_ylabel('y-axis') ax.set_title('Multiple Plots Overlayed') ax.legend()

Display the plot

plt.show()

In this code snippet, we first create two sets of sample data y1 and y2. We then create a figure and subplot using plt.subplots(). We overlay the two plots on the same subplot by calling ax.plot() twice with different sets of data. Finally, we add labels, title, and a legend to the plot before displaying it using plt.show().
