To customize the font size and style in Matplotlib, you can use the following methods:
- Set the font size: Use the plt.rcParams['font.size'] property to set the default font size for text elements in the plots. Example: plt.rcParams['font.size'] = 12
- Set the font family/style: Use the plt.rcParams['font.family'] property to set the default font family for text elements in the plots. Example: plt.rcParams['font.family'] = 'serif' To set a specific font style, you can use the fontstyle parameter while plotting specific text elements. Example: plt.text(x, y, 'Text', fontstyle='italic')
- Adjust font size/style for individual text elements: When plotting specific text, you can set the font size and style using the fontsize and fontstyle parameters respectively. Example: plt.text(x, y, 'Text', fontsize=14, fontstyle='italic')
- Change the title font size: Use the plt.title function to set a title for the plot. To change the font size of the title, use the fontsize parameter. Example: plt.title('Title', fontsize=16)
- Change the axis label font size: The x-axis and y-axis labels can be customized using the plt.xlabel and plt.ylabel functions respectively. To change the font size of the axis labels, use the fontsize parameter. Example: plt.xlabel('X Label', fontsize=14)
- Change the tick labels font size: The tick labels on the x-axis and y-axis can be customized using the plt.xticks and plt.yticks functions respectively. To change the font size of the tick labels, use the fontsize parameter. Example: plt.xticks(fontsize=12)
Overall, these methods allow you to customize the font size and style in Matplotlib, enabling you to create visually appealing plots as per your preference.
Best Matplotlib Books to Read in 2024
How to customize the font family in Matplotlib?
To customize the font family in Matplotlib, you can follow these steps:
- Import the necessary libraries:
1 2 |
import matplotlib.pyplot as plt import matplotlib.font_manager as fm |
- Get the available font names:
1
|
font_names = fm.findSystemFonts()
|
This will return a list of available fonts on your system.
- Select a font from the available options:
1
|
font_path = fm.FontProperties(fname=font_names[0]).get_file()
|
You can choose any font from the list based on your preference by changing the index.
- Set the font family for your plot:
1
|
plt.rcParams['font.family'] = fm.FontProperties(fname=font_path).get_name()
|
This line sets the selected font as the default font family for your plot.
- Display your plot:
1 2 3 4 5 |
plt.plot([1, 2, 3, 4], [1, 4, 9, 16]) plt.xlabel('X-axis', fontsize=12) plt.ylabel('Y-axis', fontsize=12) plt.title('Customized Font Family', fontsize=14) plt.show() |
This code will create a basic line plot with customized font family settings.
Remember to replace font_names[0] with your desired font index if you want to use a different font.
How to change the font size only for y-axis labels in Matplotlib?
To change the font size of only the y-axis labels in Matplotlib, you can use the tick_params method of the y-axis object (ax.yaxis), and pass the argument labelsize to specify the desired font size. Here's an example:
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 |
import matplotlib.pyplot as plt # Create sample data x = [1, 2, 3, 4, 5] y = [10, 20, 30, 40, 50] # Create a figure and axis fig, ax = plt.subplots() # Plot the data ax.plot(x, y) # Set font size only for y-axis labels ax.yaxis.tick_params(labelsize=12) # Show the plot plt.show() |
In the above example, the labelsize argument set to 12 will change the font size of only the y-axis labels.
How to make the font italic in Matplotlib?
To make the font italic in Matplotlib, you can use the fontstyle parameter of the text properties (plt.text() or ax.text()) or the set_fontstyle() method of a Text object.
Here's an example:
1 2 3 4 5 6 7 8 9 10 11 |
import matplotlib.pyplot as plt # Using text properties plt.text(0.5, 0.5, 'Italic Text', fontstyle='italic') # Using a Text object fig, ax = plt.subplots() text = ax.text(0.5, 0.5, 'Italic Text') text.set_fontstyle('italic') plt.show() |
In both examples, the text "Italic Text" will be displayed in italic font.
