How to Read Async Server Side Streaming Using Grpc C++?

Published on
4 min read

Table of Contents

Show more
How to Read Async Server Side Streaming Using Grpc C++? image

To read async server-side streaming using gRPC C++, you first need to define the service and messages in a .[proto](https://allarticle.undo.it/blog/what-does-proto-in-ember-js-mean) file. Then you need to generate C++ code from the .proto file using the Protocol Buffers compiler. Next, implement the server-side streaming function in your C++ server application by defining a gRPC service handler that returns a grpc::ServerWriter object. This ServerWriter object is used to write response messages back to the client asynchronously.

In the client application, you can create a gRPC channel to connect to the server and call the server-side streaming function. You will receive a grpc::ClientReader object, which you can use to read response messages from the server asynchronously.

To read the server-side streaming responses, you can loop over the Reader object's Read() method, which returns true if a message was successfully read and false if the stream has ended. You can then process the received message as needed.

Remember to handle any errors that may occur during the server-side streaming communication to ensure that your application behaves robustly.

What is server side streaming in gRPC?

Server-side streaming in gRPC allows the server to send multiple responses to a client in a single RPC call. This means that the server can start sending responses as soon as they are available, rather than waiting until all the data is ready to send it all at once. This is useful in cases where the server needs to send a large amount of data, such as when streaming real-time updates or a large set of results. The client can start processing the responses as they are received, which can improve performance and reduce latency.

How to handle authentication in gRPC server side streaming?

Authentication in gRPC server side streaming can be handled by using interceptors in your gRPC server. Here is how you can implement authentication in gRPC server side streaming:

  1. Define a custom interceptor that handles authentication. This interceptor should check the incoming request for authentication credentials, validate them, and either allow or reject the request based on the authentication result.

public class AuthenticationInterceptor implements ServerInterceptor {

@Override
public <ReqT, RespT> ServerCall.Listener<ReqT> interceptCall(ServerCall<ReqT, RespT> call, Metadata headers, ServerCallHandler<ReqT, RespT> next) {

    // Check the incoming request for authentication credentials
    String token = headers.get(Metadata.Key.of("token", Metadata.ASCII\_STRING\_MARSHALLER));

    // Validate the authentication token
    if (isValidToken(token)) {
        // Authentication successful, proceed with the request
        return next.startCall(call, headers);
    } else {
        // Authentication failed, reject the request
        call.close(Status.UNAUTHENTICATED.withDescription("Invalid authentication token"), headers);
        return new ServerCall.Listener<ReqT>() {};
    }
}

private boolean isValidToken(String token) {
    // Add your code here to validate the authentication token
}

}

  1. Register the custom interceptor with your gRPC server. You can do this when building the server instance.

Server server = ServerBuilder.forPort(port) .addService(ServerInterceptors.intercept(serviceImpl, new AuthenticationInterceptor())) .build();

  1. Ensure that the client sends the authentication token in the metadata of each request when making server side streaming calls.

Metadata headers = new Metadata(); headers.put(Metadata.Key.of("token", Metadata.ASCII_STRING_MARSHALLER), "your_authentication_token_here");

Stub stub = YourServiceGrpc.newStub(channel); stub.withInterceptors(MetadataUtils.newAttachHeadersInterceptor(headers)) .yourServerSideStreamingMethod(yourRequest);

With these steps, your gRPC server side streaming calls will be authenticated using the custom interceptor that checks for authentication credentials in the incoming requests.

How to create a channel in gRPC C++?

To create a channel in gRPC C++, you need to use the grpc::CreateChannel() method provided by the gRPC library. Here is a basic example of how to create a channel:

#include <grpcpp/grpcpp.h>

using namespace grpc;

int main() { // Create a channel to the gRPC server std::shared_ptr channel = grpc::CreateChannel("localhost:50051", InsecureChannelCredentials());

// Check if the channel is successfully created
if (channel) {
    std::cout << "Channel created successfully" << std::endl;
} else {
    std::cerr << "Failed to create channel" << std::endl;
}

return 0;

}

In the example above, we first include the necessary headers for gRPC C++. We then create a shared pointer to a Channel object by calling the grpc::CreateChannel() method with the server address and credentials. In this example, we are using insecure channel credentials (InsecureChannelCredentials()), but in a production environment, you should use secure channel credentials. Finally, we check if the channel was created successfully and print a message accordingly.

Make sure to update the server address "localhost:50051" with the actual address of your gRPC server.
