How to Show Composite Indexes In MySQL?

11 minutes read

To show composite indexes in MySQL, you can use the SHOW INDEX statement. This statement displays the index information of a table, including composite indexes.

Here is the syntax for using SHOW INDEX statement in MySQL:

SHOW INDEX FROM table_name;

In the above syntax, you need to replace table_name with the actual name of the table for which you want to see the composite indexes.

When you execute the SHOW INDEX statement, it will return a result set with the following columns:

  • Table: Name of the table on which the index is created.
  • Non_unique: Indicates whether the index allows duplicates. A value of 0 means the index is unique, and a value of 1 means it allows duplicates.
  • Key_name: Name of the index.
  • Seq_in_index: The sequence number of the column within the index. For composite indexes, this field represents the position of the column in the index.
  • Column_name: Name of the column included in the index.
  • Collation: The collation used for the column.
  • Cardinality: The estimated number of unique values in the index.
  • Sub_part: Specifies a partial length for a prefix index if present.
  • Packed: Indicates if the index is packed.
  • Null: Contains 'YES' if the column can contain NULL, or empty string if not.
  • Index_type: Type of the index.
  • Comment: Any additional comments regarding the index.

By examining the results from the SHOW INDEX statement, you can easily identify the composite indexes in a MySQL table. Composite indexes are those that have multiple columns specified in the Column_name and Seq_in_index columns. Each column name will be listed in sequential order according to their position in the composite index.

Note that composite indexes can be created using the CREATE INDEX statement, specifying multiple columns to be included in the index definition.

Best Managed MySQL Hosting Providers in 2024?


Rating is 5 out of 5



Rating is 4.9 out of 5



Rating is 4.8 out of 5



Rating is 4.7 out of 5


What is the impact of table compression on composite index performance in MySQL?

Table compression can have both positive and negative impacts on composite index performance in MySQL. Here are some key points to consider:

  1. Improved disk space utilization: Table compression reduces the size of data on disk, allowing more data to be stored in available space. This can potentially result in better overall performance by reducing the need for disk I/O operations.
  2. Reduced I/O operations: Smaller compressed data means fewer disk reads and writes during query execution. This can lead to improved performance, especially when reading a large amount of data from the disk.
  3. Increased CPU usage: Compression and decompression of data require additional CPU resources. While modern CPUs are usually capable of handling compression efficiently, complex queries or high query loads may result in increased CPU usage, potentially impacting overall system performance.
  4. Index size reduction: Table compression can also shrink the size of composite indexes, which reduces the amount of memory needed to cache index pages. This can result in faster index scans as fewer disk reads are required.
  5. Reduced index seek performance: While index compression can improve index scan performance, it may adversely affect index seek operations. Compressed indexes require additional CPU overhead to decompress during seek operations, potentially slowing down search performance.

Overall, the impact of table compression on composite index performance is a trade-off between improved disk space utilization and potentially increased CPU overhead. It's crucial to test and benchmark the system under different workloads to evaluate the net performance gain or loss from compression in specific use cases.

What is the effect of data distribution on composite index performance in MySQL?

The data distribution in MySQL can have a significant effect on the performance of composite indexes.

Data distribution refers to how the data is distributed across the different values in a column that is part of a composite index. The data distribution can impact the efficiency of index scans and the effectiveness of the index in reducing the number of rows that need to be examined.

If the data distribution is uneven, with a few values having a large number of rows while most values have only a few rows, it can lead to an index being less effective and potentially slower. In such cases, the index may need to scan a large number of rows to find the desired data, and the optimizer may choose not to use the index at all.

On the other hand, if the data distribution is even, with a similar number of rows for each value, it can lead to better index performance. The index can effectively narrow down the set of rows that need to be examined, resulting in faster queries.

To optimize composite index performance, it is important to analyze the data distribution and make adjustments as needed. This may involve reorganizing the data to balance the distribution or considering alternative index strategies. Using tools like EXPLAIN and analyzing the query execution plan can provide insights into the effectiveness of the index and assist in fine-tuning its performance.

What are the advantages of using composite indexes in MySQL?

There are several advantages of using composite indexes in MySQL:

  1. Improved query performance: Composite indexes allow for quicker queries as they cover multiple columns. This means that MySQL can use the composite index to efficiently search and retrieve data that matches criteria involving multiple columns.
  2. Reduced disk I/O: With a composite index, the database engine needs to read fewer blocks from disk to satisfy a query. This can significantly reduce disk I/O operations and improve overall performance.
  3. Reduced index size: Compared to maintaining individual indexes on each column, a composite index can often have a smaller size. This is beneficial as indexes require disk space and memory. A smaller index size can lead to better memory utilization and faster queries.
  4. Index merging: MySQL can merge multiple indexes into one composite index for improved query performance. This merging operation can enhance the efficiency of certain types of query access patterns, especially when searching on multiple columns simultaneously.
  5. Query optimization: Composite indexes provide the database optimizer with more options for query optimization. The MySQL query planner can choose the appropriate composite index to satisfy a query, resulting in faster response times and reduced CPU usage.
  6. Simplified index management: Instead of managing multiple individual indexes on different columns, using a composite index simplifies index maintenance. This can reduce the complexity of database administration tasks, such as index creation, deletion, and overall index management.

In summary, composite indexes in MySQL offer improved query performance, reduced disk I/O, smaller index size, index merging, better query optimization, and simplified index management. Using them effectively can significantly enhance the overall performance of database operations.

What is the difference between a composite index and a single-column index in MySQL?

A composite index in MySQL is an index that is created on multiple columns of a table, while a single-column index is created on a single column.

The main difference between these two types of indexes lies in their usage and impact on performance:

  1. Usage: A composite index is useful when queries involve multiple columns. It allows the database to efficiently search and retrieve data based on a combination of column values. On the other hand, a single-column index is helpful when queries involve a specific column, allowing for fast data retrievals based on that particular column value.
  2. Performance: A composite index can improve query performance when queries involve the indexed columns in combination. It can optimize joins, sorting, and filtering on the indexed columns. However, it may have a higher overhead in terms of storage and maintenance compared to a single-column index. A single-column index, on the other hand, is optimized for searching and retrieving data based on that specific column, providing fast lookup times.

In summary, a composite index is suitable for queries involving multiple columns, while a single-column index is more efficient for queries targeting a single column. The choice between them depends on the specific requirements and query patterns of the application.

How to use composite indexes to improve query performance in MySQL?

To improve query performance in MySQL using composite indexes, you can follow these steps:

  1. Determine which columns are frequently used together in your queries. These columns will form the basis of your composite index.
  2. Analyze your queries to identify the order in which the columns are commonly used. The order of columns in a composite index is important, as it affects the index's selectivity.
  3. Create the composite index using the CREATE INDEX statement. Specify the columns to be included in the index and their order. For example, if your frequently used columns are "column1", "column2", and "column3", you can create a composite index as follows: CREATE INDEX index_name ON table_name (column1, column2, column3);
  4. Monitor the performance of your queries with the newly created composite index. Use the EXPLAIN statement to understand how the MySQL optimizer is using the index. Make adjustments to the index order or add/remove columns based on the query execution plan.
  5. Perform query performance tests to compare the execution times before and after adding the composite index. This will help you measure the effectiveness of the index in improving performance.
  6. Consider the trade-offs. While composite indexes can speed up specific queries, they can slow down data modification operations (e.g., insert, update, delete). The index size also increases, which can impact disk space usage.
  7. Regularly review and optimize your composite indexes. Over time, as query patterns change, you may need to modify or drop existing indexes and create new ones to maintain optimal query performance.

Remember, composite indexes are most effective when used for columns frequently involved together in WHERE, JOIN, or ORDER BY clauses. It's essential to analyze your queries, monitor performance, and fine-tune the indexes to achieve the best results.

How to calculate the index selectivity of composite indexes in MySQL?

To calculate the index selectivity of composite indexes in MySQL, you can follow these steps:

  1. Determine the number of distinct values for each column participating in the composite index. You can use the following query to get the number of distinct values for a particular column: SELECT COUNT(DISTINCT column_name) FROM table_name;
  2. Multiply the selectivity of each column together to get the overall selectivity of the composite index. Selectivity is calculated as the number of distinct values divided by the total number of rows in the table. For example, if column1 has a selectivity of 0.1 (10% distinct values) and column2 has a selectivity of 0.2 (20% distinct values), the overall selectivity would be 0.1 * 0.2 = 0.02 (2%).
  3. If you want to convert the selectivity to a cardinality (estimated number of rows returned by the index), you can multiply the selectivity by the total number of rows in the table. For example, if the table has 1000 rows and the overall selectivity is 0.02, the cardinality would be 0.02 * 1000 = 20 rows.

Keep in mind that these calculations are estimates and may not reflect the actual performance of the index in practice. It is always recommended to test and analyze the query execution plan using tools like EXPLAIN to evaluate the effectiveness of composite indexes in MySQL.
