How to Save A Matplotlib Plot As an Image File?

10 minutes read

To save a Matplotlib plot as an image file, follow these steps:

  1. Import the matplotlib.pyplot module as plt: import matplotlib.pyplot as plt
  2. Create a plot using Matplotlib.
  3. Once the plot is ready, use the savefig() function to save it as an image file. The basic syntax is: plt.savefig("filename.extension"), where filename is the desired name for the file, and extension represents the image file format such as "png", "jpg", "svg", etc.
  4. By default, the image file will be saved in the current working directory. If you want to save it in a specific directory, provide the complete path along with the filename and extension.
  5. In addition to the file name, you can also customize the resolution and other parameters of the saved image by passing optional arguments to the savefig() function. For example, plt.savefig("filename.png", dpi=300) sets the resolution of the saved image to 300 dots per inch.


That's it! Your Matplotlib plot will be saved as an image file using the specified name and format.

Best Matplotlib Books to Read in 2024

1
Data Visualization in Python with Pandas and Matplotlib

Rating is 5 out of 5

Data Visualization in Python with Pandas and Matplotlib

2
Matplotlib 3.0 Cookbook: Over 150 recipes to create highly detailed interactive visualizations using Python

Rating is 4.9 out of 5

Matplotlib 3.0 Cookbook: Over 150 recipes to create highly detailed interactive visualizations using Python

3
Matplotlib for Python Developers

Rating is 4.8 out of 5

Matplotlib for Python Developers

4
Numerical Python: Scientific Computing and Data Science Applications with Numpy, SciPy and Matplotlib

Rating is 4.7 out of 5

Numerical Python: Scientific Computing and Data Science Applications with Numpy, SciPy and Matplotlib

5
Matplotlib 2.x By Example: Multi-dimensional charts, graphs, and plots in Python

Rating is 4.6 out of 5

Matplotlib 2.x By Example: Multi-dimensional charts, graphs, and plots in Python

6
Matplotlib for Python Developers: Effective techniques for data visualization with Python, 2nd Edition

Rating is 4.5 out of 5

Matplotlib for Python Developers: Effective techniques for data visualization with Python, 2nd Edition

7
Python Data Analytics: With Pandas, NumPy, and Matplotlib

Rating is 4.4 out of 5

Python Data Analytics: With Pandas, NumPy, and Matplotlib

8
Python and Matplotlib Essentials for Scientists and Engineers (Iop Concise Physics)

Rating is 4.3 out of 5

Python and Matplotlib Essentials for Scientists and Engineers (Iop Concise Physics)

9
Hands-On Data Analysis with Pandas: A Python data science handbook for data collection, wrangling, analysis, and visualization, 2nd Edition

Rating is 4.2 out of 5

Hands-On Data Analysis with Pandas: A Python data science handbook for data collection, wrangling, analysis, and visualization, 2nd Edition

10
Data Visualization with Python for Beginners: Visualize Your Data using Pandas, Matplotlib and Seaborn (Machine Learning & Data Science for Beginners)

Rating is 4.1 out of 5

Data Visualization with Python for Beginners: Visualize Your Data using Pandas, Matplotlib and Seaborn (Machine Learning & Data Science for Beginners)


How to remove the white border around a saved Matplotlib plot?

To remove the white border around a saved Matplotlib plot, you can follow these steps:


Step 1: Save the figure with a transparent background using savefig method:

1
plt.savefig('plot.png', transparent=True)


This will save the plot as a PNG image with a transparent background.


Step 2: Open the saved image in an image editing software, such as Microsoft Paint or Adobe Photoshop.


Step 3: Crop the image to remove the white border.


Step 4: Save the cropped image.


By following these steps, you should be able to remove the white border around the saved Matplotlib plot.


What is the command to change the DPI (dots per inch) of a saved Matplotlib plot?

To change the DPI (dots per inch) of a saved Matplotlib plot, you can use the savefig() function with the dpi parameter. Here's an example command:

1
2
3
4
5
6
7
8
import matplotlib.pyplot as plt

# Create and plot the figure
fig, ax = plt.subplots()
ax.plot([1, 2, 3, 4], [1, 4, 9, 16])

# Save the plot with a specified DPI (e.g., 300)
plt.savefig('output.png', dpi=300)


In this example, the savefig() function is called with the dpi parameter set to 300, resulting in a high-resolution plot with a DPI of 300 saved as "output.png". You can adjust the value of dpi to meet your specific requirements.


How to save a Matplotlib plot as a PNG file?

To save a Matplotlib plot as a PNG file, you can use the savefig() function. Here is an example of how to do it:

1
2
3
4
5
6
7
import matplotlib.pyplot as plt

# Create a plot
plt.plot([1, 2, 3, 4], [1, 4, 9, 16])

# Save the plot as a PNG file
plt.savefig('plot.png')


In this example, the savefig() function is used to save the current figure as a PNG file with the name plot.png. You can specify the path and filename of the PNG file to save it in a specific location.


After running this code, you will find a file named "plot.png" with the plot saved as a PNG image.


What is the method to customize the font size of axis labels in a saved Matplotlib plot?

To customize the font size of axis labels in a saved Matplotlib plot, you can use the following method:

  1. Import the required libraries:
1
import matplotlib.pyplot as plt


  1. Create your plot and set the font size of the axis labels using the set_xlabel and set_ylabel functions:
1
2
plt.xlabel('X-axis label', fontsize=14)
plt.ylabel('Y-axis label', fontsize=14)


  1. Save the plot to a file using the savefig function, specifying the desired file format and filename:
1
plt.savefig('plot.png')


Here, you can adjust the fontsize parameter in the set_xlabel and set_ylabel functions according to your preference.


This method sets the font size for both the x and y-axis labels. If you want to set the font size for only one axis, you can use the set_title function to set the font size for the x-axis label and set_ylabel for the y-axis label.


Additionally, you can also adjust the font size of tick labels on the x and y-axis using xticks and yticks functions respectively. For example:

1
2
plt.xticks(fontsize=12)
plt.yticks(fontsize=12)


Remember to call the show function after savefig if you are displaying the plot on the screen before saving it.
